发动机型式/Engine Type		直列四缸4冲程柴油机/In-Line,4 Cylinders,4 Cycle Diesel Engine
缸径/Bore		102mm
行程/Stroke		120mm
排量/Displacement		3.9L
压缩比/Compression Ration		17.3:1
调速率/Governor Regulation		机械调速器/Mechanical Governor≤8%
		电子调速器/Electrical Governor≤3%
		全电控/ECM≤1%
电气系统/Electrical System		24V
燃油系统/Fuel system		A型泵/P型泵/HPCR
机油容量/Lube Capacity		10.9L
机油型号/Lube Oil Type		15W40-CH4及以上/Higher Than 15W40-CH4
接口尺寸/Flywheel		SAE 3#  11.5时

2. Packing Info.

Packing Material	Non fumigation wooden box
Net Weight	472.00 KGS
Gross Weight	520.00 KGS
Packing Size(L*W*H)	1080*625*1085



3. Engine Family

产品型号 Type Coolpac/engine)	发动机功率 Engine Power		机组功率 Gen-set Power				排量 Displacement	调速方式 Governer
	1500rpm/1800rpm		50Hz/60Hz
	额定功率 Prime	备用功率 Standby	常用功率 Prime		备用功率 Standby
	kWm	kWm	kWe	kVA	kWe	kVA
4B-G17M1/4B3.9-G11	20/23	22/26	17/20	20/25	19/22	24/28	3.9L	机械式 Mechanical
4B-G22M1/4B3.9-G1	24/Na	27/Na	22/Na	27/Na	24/Na	30/Na
4B-G22E1/4B3.9-G2	24/30	27/33	22/24	27/30	24/27	30/34		电子式 Electronic
4B-G25E1/4B3.9-G12	27/33	30/36	25/28	30/35	27/30	34/38



4. Quality Warranty

SR	Usage Time & Mileage	Parts
1	12 months or 120,000KM which comes first	cylinder head, block, crankshaft, camshaft, con rod, flywheel cover, air compressor, valves, cylinder liner, piston, pin, ring, tappet, con rod bearing, main bearing, oil pump
2	9 months or 90,000KM which comes first	Injection pump, turbocharger, generator, starter, water pump, belt tensioner, flywheel, all sensor, all gasket, all pipes
3	6 months or 60,000KM which comes first	Clutch pressure plate, fan
4	3 months or 30,000KM which comes first	Clutch disc, V- belt
5	Warranty period for the unspecified components mentioned above is 12 months or 120,000KM which comes first.

Any behavior caused by any of the following reasons indicates that your engine has exceeded the scope of quality assurance, and our company will no longer provide corresponding quality assurance.

1. Malfunctions caused by changing the original structural state of the engine and its related components without our company’s permission.
2. Engine failure caused by inappropriate driving behavior, likeviolent driving, speeding, long-term idling, etc.
3. Failure to perform regular maintenance, including regular replacement of lubricating oil, coolant, fuel filter, oil filter, air filter, oil-water separator, etc.
4. Engine failure or damage caused by the use of unqualified coolant and lubricating oil.
5. The normal noise, vibration, wear, aging and other wear and tear of the engine.
6. Engine damage caused by uncontrollable factors such as floods, lightning, storms, hail, etc.



5. Shipment

Regular sea shipment is based on FOB term, we will arrange FCL from Wuhan port, LCL from Shanghai port. If you want to use other port of China, please indicate us in advance.

For urgent orders, we also can help to arrange the delivery by Air or by other proper ways.
